Size:
- 22″ wide x 59″ long
- Custom sizes available
- 81″ assembled height with 77″ standard post and 2″ x 5″ casters
- 84″ assembled height with 77″ standard post and 2″ x 8″ casters
- 86″ assembled height with 77″ standard post and 2″ x 10″ casters
Finish:
- Stainless-steel
- Powder coat painted
Shelf Options:
- 1/8″ x 1″ x 4″ welded wire pattern
- Solid sheet steel, riveted
Casters:
- QSP – quiet, non-marking, cushion ride feature. “Maintenance Free” precision wheel ball bearings. Sealed swivel caster raceways. 5″ x 2″ standard wheel size. Optional wheel sizes available. Wheel thread guards keep shrink wrap out
- EZ unitized ball bearing in 2″ wide x 5″, 6″ or 8″ diameter
- Quality no flat in 2″ wide x 8″ or 10″ diameter
- Standard application of 2 rigid and 2 swivel per cart
- Optional extra is Posiloc brake or Vertilok brake on 1 Swivel in 2″ wide x 5″ or 6″
- Ask us which casters work best in your environment and/or with your products
What Are They Made From:
- All stainless-steel construction, with welded wire inserts
Identification:
- Laser cut id. plates on base
Drawbars:
- Standard, reinforced or springloaded
- Length – 18″ standard
Posts:
- Standard – 12 gauge, 3/4 slot, 36 holes, 77″ long
Capacity:
- Per cart rated at 1000 lbs. (distributed load)
- Per shelf rated at 175 lbs. (distributed load)
